分散性・分散安定性評価装置 TURBISCAN DNS 製品仕様
| Acquisition scan step | 20 µm |
|---|---|
| Automatic sample recognition (bar-code) | Yes |
| CE Certified | Yes |
| Dimensions | 70 x 63 x 52 cm |
| Standards | ISO/TR 13097:2013, ISO/TR 18811:2018, ISO/TS 22107:2021, ISO/TS 21357:2022 |
| Maximum acquisition speed | 0.1 seconds (in fixed mode) |
| Maximum sample concentration | 95% v/v |
| Measured size range | 10 nm - 1 mm |
| Measurement type | At rest and under mixing conditions |
| Measuring Principle | Static Multiple Light Scattering (SMLS) |
| Particle size distribution | Yes (additional software required) |
| Number of Samples | 1 |
| Reproducibility / Repeatability on latex standards | 0.1% / 0.05% |
| Sample volume at rest | 4 or 20 mL |
| Sample volume under mixing conditions | 10mL up to Liters |
| Software | TurbiSoft + TurbiSoft Fast |
| Temperature range | RT - 60°C |
| Weight | 30 kg |
